GK Built Quad 4XBLF188XR LDMOS Linear Amplifier & 100A 50v Pwr Supply 💪

Gatekeeper Built QUAD LDMOS[4XBLF188XR] 50V Amplifier with 100A+ 50v Power Supply This was "ONE HECK OF A PROJECT"! Built over 2.5 Years ago, as of this post, ranking in at my 3rd LDMOS project. Everything turned pretty good. Just like all custom first time projects, there are a few things I would do different looking back years later now. One is building with single pallets only. So my next quad will be built using single pallets. I also plan on trying out different designs and maybe one day building my own pallet. For now I have paused at the 6 LDMOS Projects I've done and working on catching up with my other BJT Pill Box work I'm backed up on. Special thanks Details: Candy Apply Green On Both The Amp & Power Supply Broad Banded Hybrid Coupler Style Combinner & Splitter -10 DB T Attenuator[60w] 6 Variable Speed AC Fans On Top Switchable Thermal Cut Off Protection Manual Key/Xmit Jack for Padded or Radio Simple Receive Preamp Isolated Keying Circuit & External Amperage Read Out Jack Dual ESP120 Switcher Server Supplies[Built Like Tanks] Dual Common Mode Chokes for greater noise rejection across the few spectrum Special Thanks to Mr. BBI for introducing this technology to this particular scene, To Prime Minister for paving a road for us boys to drive on after he done went in and cleared out the brush and throw bushes 🤣😅🤣👍 & last but definitely not least RF Man "Tha Genius", for all those hours and hours of teachings in your work shop with me, for being a mentor & designing these pallets that entered me into the door with technology. Your a huge blessing man!!!!
