NX2306 CAM What's New - Position Part and Fixtures in Machine Control

This NX CAM video demonstrates the new functionality in Siemens NX 2306 for Manufacturing. You can now position a part on a machine using a bounding box or a bounding cylinder as a reference point. This lets you specify a coordinate system for the part with reference to the bounding box or bounding cylinder. You can then use the coordinate system to position the part on the machine. The following options are available: ✅ Hide the previous machine if replacing the machine ✅ Show the part and associated fixtures in either a bounding box or cylinder ✅ Ability to pick a snap point in the Part Mounting dialog on the bounding box or cylinder ✅ Move the part on the machine tool instead of machine around the part This provides a much better user experience and workflow preparing for programming in the context of the machine tool. ▶️More on NX CAM: https://www.cardsplmsolutions.com/en/... ▶️Subscribe to our channel:    / cardsplmsolutions   ▶️Follow cards PLM Solutions: Website: https://www.cardsplmsolutions.com/nl LinkedIn:   / cards-plm-solutions   #NX #CAM #Manufacturing #CNC #Milling #Turning #cncprogramming
