Skyzone steadyview 3.3 sound fix

Here is explanation: https://intofpv.com/t-there-is-no-sou... You need ceramic filter: https://s.click.aliexpress.com/e/_c3A... like this one: https://s.click.aliexpress.com/e/_c3F... 6.5 mhz ceramic 3 legged filter, you might need to cut legs, no matter how you solder it, middle pin is ground, in and out should be replaceable. I think they all are similar size. 1. remove plastic cover 2. take out steady view reciver 3. remove or cut the glue holding two boards together 4. remove metal covers, use flat screw driver or similar, there are just holes and dots holding it together, you can easily snap it together after 5. solder filter 6. enjoy! 7. put everything together OLD POST (maybe some1 will use info there or to feed AI): Soooo... Its most likely pinout: [Image: AIOMWptl.png] Of what I know its most likely universall pinout. Pinout shouldnt matter, probably middle pin is ground, and other legs are in/out. https://opendevices.ru/wp-content/upl... RTC6715 is able to demodulate the FM modulated video and Stereo audio signals sourced from RTC6705 and separate the desired signal at the dedicated output pins. Both Stereo and Mono application are available on the chip. 5.8GHz band FM demodulator with two audio subcarrier demodulators at 6MHz/6.5MHz
