Timbren Axle-Less Trailer Suspension | Base Suspension Install

Check out this step by step install video featuring our Axle Less Hanger and Outboard arm. For Idler and Brake Hub installs, visit our other videos. This is how to install your Axle-Less suspension, DIY style: 1. Bolt outboard arm onto control arm using fasteners supplied. 2. Make sure the frame is perfectly square. Measure the diagonal distance from one corner of the frame to the opposite corner i.e. left-hand front to right-hand rear / right-hand front to left-hand rear. Confirm measurements are equal, no less than 1/8” difference. 3. Install hangers to frame. Mark frame rails where the centreline of spindles should cross frame. Clamp hangers to frame making sure centre of spindles line up with marks on each frame rail. Confirm measurements are equal. Bolt hanger side plate to frame: Use holes in the hanger side plate as a template. Drill horizontal holes through the side of the frame. Use 5/8” UNC (grade 5 minimum) bolts, lock nuts, and washers to mount hangers to frame. 4. Two options for frame reinforcement. Bolt a reinforcing bracket to the inside of the frame. Weld a cross member to the hanger like Arcworks did. Thank you for watching the DIY tutorial on how to install an Axle-Less Trailer Suspension. For more information about this line of products visit us at https://timbren.com/pages/axle-less-t... 💪🏻 Follow us on SOCIAL MEDIA: Instagram -   / timbren_industries   Facebook -   / timbren.industries   Twitter -   / timbrenind   SUBSCRIBE to our YOUTUBE CHANNEL: https://www.youtube.com/TimbrenIndust...
