HFS-804 MTD for Rosenberger MTD®

The HFS-804 MTD series from INGUN is a modular, high-performance RF contacting solution designed for precise and reliable testing of Rosenberger MTD® connectors. With integrated pre-alignment, the HFS-804 MTD compensates for tolerances of up to ±0.5 mm in the X/Y direction and up to ±3° angular offset, enabling reliable contacting even when connector tolerances are present. Benefits at a Glance: Long service life and high mechanical reliability thanks to a robust contacting tip with protected signal conductors Reduced installation effort through a flange-mounted design for quick and straightforward integration into the test fixture Stable connection during testing ensured by using the original MTD® mating cable with locking function Simplify your testing process with INGUN’s reliable and efficient solutions! RF probe: https://ingun.com/HFS-804-306-090-A-5... Mounting plates: double: https://ingun.com/KA-804-MTD-2/KA-804... quintuple: https://ingun.com/KA-804-MTD-5/KA-804... RF cables: https://ingun.com/SE-HSD-100MTD1FG100...
