This project focuses on the implementation of the Boolean function Y = ((A + BC) · D)’ using CMOS logic. The design process follows standard steps to make a Boolean function using CMOS, including breaking the expression into basic gates, designing the Pull-Down Network (PDN) with NMOS transistors, and the Pull-Up Network (PUN) with PMOS transistors. By applying De Morgan’s theorem, the Boolean expression is optimized for CMOS realization. The Boolean function realization using CMOS ensures low power consumption and full voltage swings. This approach demonstrates how Boolean expression implementation using CMOS and implementation of Boolean function using CMOS logic is achieved in practical VLSI design. Alternative methods like implementation using NAND gates or using multiplexers (MUX) are also applicable for Boolean logic design, offering flexibility in CMOS Boolean functions design strategy.
