ND BHATT EXERCISE 9 COMPLETE SOLUTION | POINTS

Hello all in this session i have solved all the questions of ND Bhatt exercise 9 which is projection of points. Basics of Projection of Points    • BASICS OF PROJECTION OF POINTS   join my doubts forum for all engineering subjects https://t.me/enggtutor786 #ndbhatt #ed #eg #points #projection #projectionofpoints #haidersir #Draw the projections of the following points on the same ground line, keeping the projectors 25 mm apart #A, in the H.P. and 20 mm behind the V.P. #B, 40 mm above the H.P. and 25 mm in front of the V.P. #C,in the V.P. and 40 mm above the H.P. #D,25 mm below the H.P. and 25 mm behind the V.P. #E, 15 mm above the H.P. and 50 mm behind the V.P. #F, 40 mm below the H.P. and 25 mm in front of the V.P. #G,in both the H.P. and the V.P. #A point P is 50 mm from both the reference planes. Draw its projections in all possible positions. #State the quadrants in which the following points are situated: (a) A point P; its top view is 40 mm above xy; the front view, 20 mm below the top view. (b) A point Q, its projections coincide with each other 40 mm below xy.
