How to Assemble and Install an Onity HT24 Lock

How To Assemble And Install the Onity HT24 Lock Assemble battery cover 1. Use a Torx #10 screw to hold the cover into place on the bottom end 2. Assemble card reader cover 3. Use 4 Torx #10 screws 4. Place insulator as shown (0:37) 5. Assemble back plate 6. Use 6 Torx #10 screws 7. Plug privacy connector wire to motherboard NOTE: motherboards have two types of connectors... ...3 pins and 5 pins (the 3 pins; plug in as normal) (the 5 pins; plug in pins 2,3, and 4) #1 and #5 not used USE the three middle pins. DON’T USE the two outside pins 8. Plug the privacy wire to the motherboard 9. Assemble front handle 10 Use a Torx #10 screw Install Onity HT24 lockset on door block 1. Coiling privacy wire as shown (1:56) 2. Use four #2 phillip head screws 3. Plug in privacy connector 4. Assemble back cover as shown (2:16) 5. Assemble thumb turn and back handle 6. Engage deadbolt 7. Use two Torx #10 screws to secure thumb turn and back handle as shown (2:36) 8. Assemble Onity HT24 covers and install it onto the door block For more information or to purchase replacement parts, check out https://www.electroniclocksmith.com
