A short video showing all the Modbus registers for an OB115-MOD Meter with Split CT works with GivEnergy System- Modbus RTU to a Tridium Niagara controller. See video #122 for adding a Modbus device to the Tridium Niagara controller. Instantaneous values 1 Voltage Bytes=4 Hex Value=0002/0010 2 Frequency Bytes=4 Hex Value=0004/004E 3 Current Bytes=4 Hex Value=0006/0052 4 Active power Bytes=4 Hex Value=0008/0092 5 Apparent power Bytes=4 Hex Value=000A/00D2 6 Reactive power Bytes=4 Hex Value=000C/ 0112 7 Power factor Bytes=4 Hex Value=000E/0152 Total energy accumulator 8 Import active energy Bytes=4 Hex Value=0160/0800 9 Import reactive energy Bytes=4 Hex Value=0162/0A00 10 Reserve (default 0) Hex Value=0164 11 Export active energy Bytes=4 Hex Value=0166/0900 12 Export reactive energy Bytes=4 Hex Value=0168/0B00 13 Total active energy Bytes=4 Hex Value=016A/0700/0618 Production data and identification 14 Serial number Bytes=4 Hex Value=FF00 15 Manufacture code Bytes=4 Hex Value=FF02 (SHFQ ASCII) 16 Type code Bytes=2 Hex Value=FF04 17 Hardware version Bytes=2 Hex Value=FF05 18 Software version Bytes=2 Hex Value=FF06 19 Reference voltage Bytes=2 Hex Value=FF07 20 Reference current Bytes=2 Hex Value=FF08 21 SO1 constant Bytes=2 Hex Value=FF09 22 SO2 output mode 0000: kWh 0001 kvarh Bytes=2 Hex Value=FF0A 23 SO1 output 0000 0.001kWh/imp 0001 0.01kWh/imp 0002 0.1kWh/imp 0003 1kWh/imp(default) Bytes=2 Hex Value=FF0B 24 SO1 pulse width 0000 60ms 0001 100ms 0002 200ms(default) Bytes=2 Hex Value=FF0C 25 Active energy measurement type 01 : Total=Import 04: Total=Export 05: Total=Import + Export 06: Total=Export-Import 09: Total=Import-Export Bytes=2 Hex Value=FF19 26 Modbus id Bytes=2 Hex Value=0524 27 Baud rate Hex(04B0) 1200bps Hex(0960) 2400bps Hex(12C0) 4800bps Hex(2580) 9600bps Hex(4B00) 19.2kbps Bytes=2 Hex Value=0525 28 Network Parity Stop 0000 None parity 0001 Even parity Bytes=2 Hex Value=0526
