Piazzamento dei chiodini e tracciatura del contorno del fondo

Come fare i fori per i chiodini di posizionamento e la tracciatura del contorno delle fasce in un'unica operazione, per assicurare la precisione del successivo riposizionamento delle fasce utilizzando i chiodini ENGLISH TRANSLATION of the written notes in the video: 00:00 - Placement of the locating pins and drawing the outline 00:13 - Lightly mark the ribs position on the centerline with a pencil 00:30 - Mark the center of pins at 3 mm scarce from the ribs line 00:37 - .... at the point corresponding to the inside line of the purfling 00:46 - Use a piece of hardwood pre-drilled perpendicular to the plane... 00:56 - .... positioning it accurately using a drill bit of the same diameter of the pins (1.75 mm) 01:23 - Make sure that the drill make a through hole 01:31 - Drill the hole using the guide to ensure perpendicularity 01:48 - Repeat the process and make also the second hole 01:57 - Make the pins using drill bits identical to the one used to make the holes 02:06 - Carefully replace the ribs on the marks made previously 02:23 - .... and secure tightly with four clamps, protecting the gluing surface of the blocks 02:52 - Turn the whole thing resting on the clamps, making sure it is stable 02:59 - Using the hole in the back as a guide, drill into the block.... 03:04 - .... to a depth of 5 or 6 mm maximum.... 03:09 - .... to avoid "enter" into the hole of the endpin at the lower block 03:33 - Do not remove the clamps and proceed with tracing the ribs outline 03:42 - Trace the outline of the ribs with a sharp marking point 04:20 - Using a washer as a spacer, mark with pencil the outline of the edges (2.5 mm from the ribs) 05:13 - Mark finally the space for the button (24 mm width, 19 mm height from ribs) Index of videos: http://davidesora.altervista.org/videos/ Website: http://www.davidesora.it/
