Water Level Indicator Using NOT Gate | Digital Logic Design Project | AIUB | Spring 21-22

Name: Munna, Shihab ID: 18-36025-1 Subject Name: Digital Logic Design Section: B Course Instructor: Chowdhury Akram Hossain Semester: Spring 2021-22 Degree Program: BSc CSE American International University-Bangladesh Project Name: Water Level Indicator System Using NOT Gate Purpose Of This Project: In this project I’m going to develop a system to measure the level of tank water. Basically I want to develop a device that can warn the user when the water level crossed a certain level. So user can easily turn off the motor switch to prevent the loss of water. On the contrary this device also remind the user when the water tank is empty. So user can turn on the motor switch to avoid inconvenience. Equipment: 1) IC 7404 2) BC 547 Transistor. 3) Resistor (10k ohm, 220 ohm) 4) Breadboard. 5) Jumper Wire. 6) LED 7) 11.1v Battery 8) 7805 Mosfet Simulation File: https://drive.google.com/drive/folder... Reference: Chowdhury Akram Hossain Sir’s YouTube Channel    / akramayaz1
