BRX PLC: Unlock Precise Speed Measurement with Timer Mode

The High-Speed discrete inputs can be configured to measure the amount of time between pulses. When you want a scaled value representing a speed or rate, the high-speed input timer is a better option for pulse rates below 5 kHz. This is compared to using the high-speed input pulse counting selection. The BRX Do-More series of programmable logic controllers have built-in high-speed inputs. These inputs can function in Counter, Timer, or Pulse Catch modes. Every CPU will have either 6 or 10 high-speed inputs (HSI) available depending on the model. These inputs can be used for input frequencies from 0 to 250Khz. 250Khz represents 250000 input counts per second that can be coming from devices connected to your PLC like an encoder. Due to the speed of the inputs, they function on the BRX Do-More PLC asynchronous with the PLC scan time. We will continue looking at the high-speed inputs on our BRX Do-More PLC, by looking at the pulse timer mode. Previously we looked at the high-speed count mode of the PLC. We scaled the count to display RPM (Revolutions per Minute). Scaling the edge trigger timer from our incremental encoder, we will scale and compare the RPM from last time. Let’s get started. More information can be obtained on our website. This includes all of the links mentioned in this video. https://accautomation.ca/brx-do-more-... The entire BRX Series PLC can be found at the following location: https://accautomation.ca/series/brx-d... 00:00 BRX Do-More PLC High-Speed Input Timer 01:55 Wiring Incremental Encoder to BRX Do-More PLC 02:54 Hardware 03:21 BRX Do-More High-Speed Input Timer Programming 07:35 Testing the BRX Do-More High-Speed Input Counter Here are some of the individual posts with video links: Installing the Software https://accautomation.ca/brx-plc-inst...    • BRX Do-More PLC Installing the Software   Establishing Communication https://accautomation.ca/brx-plc-esta...    • BRX Do-More PLC Communication Setup - USB,...   Numbering Systems and Addressing https://accautomation.ca/brx-plc-numb...    • BRX Controller Memory Allocation | Do-More...   First Program https://accautomation.ca/brx-plc-firs...    • Master Your First BRX PLC Program: Start-S...   Timers https://accautomation.ca/brx-plc-timers    • BRX Do-More PLC Timer Instructions Program...   Counters https://accautomation.ca/brx-plc-coun...    • BRX Do-More PLC Counters   High-Speed IO https://accautomation.ca/brx-plc-high...    • BRX PLC High-Speed IO Breakthrough: Real-T...   Compare Instructions https://accautomation.ca/brx-plc-comp...    • BRX Do-More PLC Compare Instructions   Shifting Instructions https://accautomation.ca/brx-plc-shif...    • BRX Do-More PLC Shifting Instructions   Drum Instruction https://accautomation.ca/brx-plc-drum...    • BRX Do-More PLC Drum Instruction Sequence!🚦   Data Logging https://accautomation.ca/brx-plc-data...    • Easy BRX Do-More PLC Data Logging Tutorial...   Email – Text SMS Messaging Gmail https://accautomation.ca/brx-plc-emai...    • BRX Do-More PLC Email – Text SMS Messaging...   Secure Email Communication    • BRX SSL/TLS Secure Email Setup: Complete I...   Dynamic Web Pages https://accautomation.ca/brx-do-more-...    • BRX Do-More PLC Dynamic Web Pages   BRX Do-More PLC FTP Client Get Put https://accautomation.ca/brx-do-more-...    • BRX Do-More PLC FTP Client Get Put   Do-More Designer Element Browser https://accautomation.ca/do-more-desi...    • Unlock Hidden Do-More Designer Browser Sec...   BRX Do-More PLC High-Speed Input Counter https://accautomation.ca/brx-do-more-...    • BRX Do-More PLC High-Speed Input Counter   There are several reasons why we are using the BRX Series Controller. Here are just a few. Standalone PLC with built-in I/O Built-in Data Logging Communication ability - Ethernet Port, RS232, RS485, USB - support for protocols such as Modbus RTU, Modbus TCP, ASCII, K-sequence (DirectLOGIC users), Custom Protocols (ASCII over serial, TCP or UDP over Ethernet) Built-in Analog input and output Integrated motion control High-speed counters Powerful instruction set (Video of Instructions in software) Ability to expand the system with a variety of modules Part of the Do-More series of PLCs which use the same free software. (Do-More Designer) Integrated simulator in the software capable of external communications for testing The BRX series of programmable logic controllers consist of four different units. They differ depending on the Inputs and Outputs built into the unit and if it has the ethernet port. No I/O Micro PLC unit – (BX ME) 10 Point Micro PLC unit – (BX 10/10E) 18 Point Micro PLC unit - (BX 18/18E) 36 Point Micro PLC unit - (BX 36/36E) These CPUs (Central Processing Units) are also known as MPU (Multi-Processing Units) because of their communication capabilities. https://www.accautomation.ca
