MCH-6/SH Compressor - How to use it for the first time

First start of our MCH-6/SH model taken out of the box with this tutorial video. COMMISSONING NEW UNIT 00:53 Measure 350ml supplied Coltri ST755 synthetic oil 01:04 Remove crankcase vent cap with 14 mm spanner 01:10 Remove oil filler cap 01:14 Fill unit with 350ml Coltri ST755 synthetic oil 01:23 Check oil sight glass for correct oil level 01:30 Replace oil filler cap and crankcase vent cap 01:47 Remove Honda engine oil filler plug 01:57 Fill Honda engine with 600 ml 10W/30 engine oil 02:05 Replace Honda engine filler plug 02:16 Fill the Honda engine Gasoline tank with gasoline 02:30 Open Filter and Condensate drain taps 02:37 Open Gasoline on/off tap 02:40 Close choke lever 02:43 Set throttle to 30% 02:47 Turn Honda engine ON/OFF switch to ON 02:50 Use pull cord to start engine 02:55 When engine starts open the Choke lever 02:58 Set throttle to MAXIMUM 03:01 Run unit for 3 minutes with drain taps open 03:03 After 3 minutes turn throttle to minimum 03:06 Switch off engine using ON/OFF switch 03:08 Check Compressor oil level, adjust level if necessary 03:14 Check Engine oil level, adjust level if necessary INSTALL / REPLACE FILTER CARTRIDGE 03:27 Use 27mm spanner to remove filter housing top plug 03:38 Remove carbon/molecular sieve filter from Packaging 03:50 Lubricate filter top plug with Food grade silicone grease 03:56 Fit the Carbon/Molecular filter, noting the o ring to the top 04:02 Replace filter top cap TANK FILLING OPERATION 04:20 Open condensate and filter drain taps 04:30 Attach filling connector to cylinder valve 04:38 Ensure Cylinder valve is closed 04:40 Open Gasoline on/off tap 04:42 Close choke lever 04:45 Set throttle to 30% 04:48 Turn Honda engine ON/OFF switch to ON 04:51 Use pull cord to start engine 04:57 When engine starts open the Choke lever 05:00 Set throttle to MAXIMUM 05:04 Close Condensate and filter drain taps 05:13 Leaving cylinder valve closed bring pressure in unit up to maximum to check operation of final safety valve 05:17 When final safety valve vents at correct pre set pressure open cylinder valve and continue filling cylinder. (If Final safety valve does not vent at correct pre set pressure contact your nearest Coltri authorized service center) 05:26 Whilst filling cylinder drain the collected condensate every 10-15 min by opening the condensate and filter drain valve until all liquid is expelled then close 05:36 When desired cylinder pressure is reached as shown on pressure gauge Turn off Honda engine using ON/OFF switch 05:39 Reduce Honda engine throttle to Minimum 05:42 Close Gasoline on/off tap 05:45 Close cylinder valve 05:51 Open Condensate drain valve 05:55 Open Filter drain tap 05:59 Remove Cylinder filling valve connection ---- Primo avvio del nostro modello MCH-6/SH estratto dalla scatola con questo video tutorial. ---- Explore our world : https://www.coltri.com/ Follow us on social media 🔵Facebook:   / aerotecnicac.  . 🔵Instagram:   / coltricompr.  . 🔵Linkedin:   / coltr.  .
