CNC cutting saw center for aluminum upvc profiles LJQZ3-CNC-550×6500

CNC cutting saw center for aluminum upvc profiles LJQZ3-CNC-550×6500 Steve Song (marketing engineer) _Jinan Sinon CNC Machine Co Ltd What's app / wechat : +86 186 5316 1193 Email: steve@sinonmachine.com Web: www.sinonmachine.com 1. This machine is a CNC intelligent cutting center developed by our company for large-scale green energy-saving aluminum processing enterprises. It is suitable for the cutting of super-large materials (45°, 90°) with a width of 180MM and a height of 150MM. 2. The machine adopts industrial control computer system and imported bus servo drive control unit, which is used for high-efficiency sawing and intelligent processing of aluminum alloy profiles. Through the intelligent combination of software, it can cut 45°, 90°, 45°, 90°, and 90° separately. , 45° two-angle combination to optimize cutting. Due to the advanced mechanical mechanism, the machine itself has the advantage of cutting to 100%. Cutting a single segment size only consumes a loss of the thickness of the saw blade, which is more helpful to the limit of 100% of the door and window design optimization rate Optimization rate. Due to the small empty stroke of the double bottom saw structure, the cutting efficiency is extremely high. The double 45° self-equipped material cutting function solves the problem of material sweeping. The cutting surface roughness is extremely high. The cutting volume is about 8 hours in a single shift About 2500-3000 roots, an average of about 10 seconds/about 1 segment, which greatly improves the cutting quality and production efficiency. 3.The machine is composed of five parts: feeding and conveying module, feeding module, sawing module, discharging module and discharging output module, so as to realize automatic optimization, sizing, cutting, and discharging from manual feeding to finished material. Input power source 380V/50Hz Working air pressure 0.6～0.8MPa Air consumption 200L/min Total power 15kw Chip removal speed 4m/min Spindle motor speed 2850r/min Saw specification ∮550×4.4×∮30×120 Cutting angle 45º / 90º Cutting width*height 90° / 45° 200×150mm Cutting accuracy ±0.2mm for cutting length Cutting surface perpendicularity ≤0.1mm Angle accuracy 4＇～6＇ Dimension 14000×4000×2400mm Weight 5500kg Steve Song (marketing engineer) _Jinan Sinon CNC Machine Co Ltd What's app / wechat : +86 186 5316 1193 Email: steve@sinonmachine.com Web: www.sinonmachine.com #processing center,aluminum processing,aluminum works,aluminum profiles,aluminum cutting center,emmegi,schuco,fom industries,mecal,mepal,urban machinery,elumatec,aluminum processing center,window machines,door machines,profile cutting machines,profile machines,yilmaz machine,kaban machine,machining centres,welding machine,pvc window production,window production line,windows and doors,how to produce pvc window,upvc window production
