A Complete Guide On How To Make Your Own BNC/SDI Cables With Tips

Do you want to master your craft in making the best SDI cables out there? Then look no further! This is a more in depth video compared to my previous one, as I show you exactly how every process is supposed to be. For the simplified version, please check this video out instead: 10 Easy Steps to Make Your Own SDI Cable:    • How To Make Your Own BNC/SDI Cable - 10 Ea...   Below are the tools I use. Some of the links in this video are affiliate links, meaning if you click through and make a purchase, I may earn a commission at no extra cost to you ;) Klein Tools Wire Cutter 11055: https://amzn.to/4gG2crL Paladin 1240 CST Coax Stripper 3-Level: https://amzn.to/3PnlBl1 Paladin Tools Crimper 8000 HDTV Universal: https://amzn.to/40lf3JW PA-2699 HDTV Universal Die Set: https://ebay.us/QVYnhE Kings 2065-10-9 BNC Crimp Connector: https://ebay.us/pnna0T Belden 1505A: https://ebay.us/WPTgMq Seating/flaring Tool RG59/6 (RECOMMENDED): / BNC Plug (Alternative): https://amzn.to/4fKZShF Generic razor blade (RECCOMENDED): https://amzn.to/4h5lMgz DBX CT3 Cable tester (RECCOMENDED): https://amzn.to/40mLU1g / Multimeter (Alternative): https://amzn.to/4gJqiSk Ruler (Optional): https://amzn.to/405QKhJ Magnifying glass (Optional): https://amzn.to/4gFwScp Makita Heat Gun HG6530VKIT (Optional): https://amzn.to/40mNArB / Lighter (alternative): https://amzn.to/3W6KlBW Strain Relief Boot (Optional) / Heat Shrink Tube (alternative): https://amzn.to/3ZWBhk0 Chapters: 0:00 - Tools needed and compatibility 0:12 - Prepare the cable 0:25 - Slide the heat shrink tube and the ferrule (crimp sleeve) 0:42 - Cutting the cable in 3 different parts + tips 1:50 - What to do in case the insulation is not coming off to expose the conductor? 2:14 - Inspect your cuts, make sure the are no debris or offcuts 3:00 - Keep the braided shield intact 3:22 - Mistakes on crimping the center pin to the conductor 3:52 - Trim the conductor to lengh if necessary / use a ruler if needed 4:46 - We don't want a gap! 5:00 - Use the separating tool to get the braided shield away from the insulation 5:40 - Aligning and getting ready to crimp 6:14 - Crimping the bad boy! 6:28 - Check your crimping work was good 6:40 - Getting ready to put the body connector 7:12 - Connecting the body connector / click and check your work 7:30 - Get ready to place the outer ferrule (crimp sleeve) in place 8:18 - Crimping the outer ferrule 8:50 - Get ready to do the heat shrink tube 9:18 - Shrinking the tube with the heat gun 9:40 - Get ready to test it if you have already done both sides and test it 10:00 - Alternative to the heat gun, the lighter, but be careful, use at your own discretion and final comments Donations are welcome. Thank you for your support! - paypal.me/greenpeak
