Plywood core veneer builder veneer core composer veneer jointer How veneer from core to panel ? скачать в хорошем качестве

Plywood core veneer builder veneer core composer veneer jointer How veneer from core to panel ?

plywood veneer jointing machine jointer, plywood production line veneer jointing core composer machine, Core composer, Veneer core composer, Veneer core composer buider, Core composer hot melt gule, Core composer machine for plywood making machine, Core composer machine price, veneer jointing core composer machine, core veneer jointer core veneer composer composing veneer sewing veneer stitching machine, plywood production line veneer jointing core composer machine, Core composer, Veneer core composer, Veneer core composer buider, Core composer hot melt gule, Core composer machine for plywood making machine, Core composer machine price, veneer jointing core composer machine, core veneer composing Veneer Composer (Veneer Core Builder) core veneer composer machine veneer sewing machine veneer stitching machine The machine is mainly used for the production of three-ply board,sandwich board, LVL,floor substrate, furniture panel, building film face board, container board, Melamine Faced Board etc, and it can also be used for the vertical splicing of rotary cut median plate with the thickness of 0.5-5.0mm.this changes the traditional manual decking technology and makes plywood decking unitized and automatic. Working principle The core veneers (1.0-4.0mm thickness panels) after drying may have different length and thickness, and the shapes may get irregular, this core veneer composing machine can detect width, thickness, cavities of the core veneer , trimmed, glued, composed,cut to length and stacked automatically. With this machine, the core veneer with different sizes can be composed in one whole sheet. Working process 1. feeding delivery----2. plate correction----3.the former drive----4. cut and control-----5. after the drive----6.docking puzzle----7.finished plate cut off The entire operation process only by a person operation. Finished plate, small material in theboard, abandoned scrap, can be stitching, not only saves the cost, but also saves the artificial. Our factory main product include: log debarker , veneer peeling machine , glue spreader , veneer composer , cold press machine , hot press machine, sanding machine ,edge trimming saw etc. Your OEM machines Welcome your kind inquiry and visit our factory! Main apply to plywood manufacture industry,suit for splicing the plywood raw material. The choppy, irregular slab, or a regular small material spliced into the whole format of the finished aniseed board.   Advantages 1. Increase production for better core  2. Easy to use 3. Less maintenance  4. Good plywood quality   Product Features:   1. Simple Operating & Economical Running Cost   2. Accurate Thickness Control   3. Hot Melt Edge - Gluing Applicator   4. Automatic Stacker System   5. Servo Drive System   Product technical specification:  core veneer composer Model ZPSF3-3 Working veneer width 968-1270 mm (3-4ft) Cutting veneer length 1220-2560 mm (4ft, 5ft, 6ft, 7ft, 8ft) Working veneer thickness 1.2-3.6 mm Length of knife 1400 mm Feeding speed 0-40m/min Thickness detecting 20 points Over thickness detecting 3 points Electric power requirement 380V-50Hz 3phase Cutting power 4.5kw X 1pc Transfer power 3kw X 2pcs After the knife power 3kw X 1pc Raise power 3kw X 1pc Transfer power 1.5kw X 3pcs Push the veneer power 1.5kw X 1pc Heater power 7.5kw Glue Applicator power 0.2kw Cool Fan power 0.75kw X 3pcs Refrigeration system 1.5Hp Air compressor power 3.7kw (7kg/cm air pressure. 1200 liters/min) Area occupied (W x L) 2300X13000mm Main machine 3800X2300X2200mm Push veneer system 4000X1900X2300mm Output 300-350pcs/hour (4x8ft) Weight 5000kgs Shipping measurement 25cbm   main parameter     Name of   the machine Servo automatic splicing machine Orign The power of the cutter 4.5kw Taiwan The power of the transfer 3kw Taiwan After the knife 3kw Taiwan Push the crib 1.5kw Rushan Overall dimension     main 3.8m*2.3m*2.2m   the stacker 4m*1.9m*2.3m The gross weight   5T         The total power 21kw Product size 2.3m*13m 1. It requires one operator only.   2. This machine is controlled completely by PLC numeric type that is very exact to improve      auxiliary device and meet the action of loading extent.To revise the control  can reduce         machines ear and improve noisy condition.   3. This machine operates with simultaneous transport operation joint exactly that is not only      perfect but also improve efficiently the old style of conventional pressing joint which easily      causes defect of overlaps, so it is a high efficient type. 4. Every operation process of this machine is installed with fan protection from dust to keep veneer material clean and nest on operation.
