uOS Codesys configuring EtherCAT within Codesys (u-OS) Weidmueller

This is the second in a series of Videos on the basics, and setup of EtherCAT using Weidmueller UC20 controller, and UR20 remote I/O. Useful links EtherCAT Technology group https://www.ethercat.org/en/technolog.... RealPars – What is EtherCAT    • What is EtherCAT?   Automation & Software | Weidmueller COM Site https://eshop.weidmueller.com/en/c/gr... 00:00 - Introduction 00:30 - Opening Codesys and creating a project 01:15 - Selecting the Weidmuller controller in Codesys 02:14 - Adding System bus modules (local I/O) 03:58 - Importing ESI Files 05:30 - Adding an EtherCAT Master 06:18 - Binding the 2nd port (ETH1) of the controller to the EtherCat fieldbus 07:40 - Adding an EtherCAT slave by scan 08:41 - Paramertising EtherCAT based I/O modules 11:18 - UR20 Manual to find parameterisation info 17:35 - Testing EtherCAT modules without a POU / TASK 18:42 - Build and go online to the controller 19:30 - Checking Codesys SL runtime is running o.k. via controller webserver 22:08 - Download project, and basic explanation of licensing
