IR Remote Test – MECHA C1 and C2 Controllers

The purpose of this video is to show you how to check if your IR Remote Commander and Receiver for MECHA is working properly (for firmware version (1)2372). To be able to perform the "IR Remote Test", you need to connect the Receiver to the Aux Port of the C1 or C2 Controller used. Then power on MECHA as usual, by long pressing the power button. The next step is to start the test by deactivating the usual functions of the Commander buttons. Let's see how this should be done for each of the controllers. If you are using a C1 Controller, enter the code 3231. Make sure you have entered it correctly (MECHA shows the entered codes on its LEDs), then use the left arrow button to confirm. This deactivates the functions of the Commander buttons, and - an important detail - it automatically enables the "Use Nodal Ninja IR Remote" option. With older firmware versions, you need to enable this option manually, either on the config page (after connecting to MECHA's Wi-Fi network) or using the code: 3232 (in fact, this code allows you to switch between enabled and disabled states). The LED under the power button of the C1 Controller keeps blinking during the test. With the Commander button functions deactivated, MECHA no longer executes remote control commands. Instead, when you press a Commander button, MECHA beeps and shows on its LEDs the code of the pressed button (after the button is released). The small LED near the cable on the IR Receiver should also flash. If you press any button on the controller (except for the power button), MECHA will beep and display the button code on its LEDs. The Receiver will not flash its LEDs. Each Commander button has its own code. If the LEDs of C1 Controller show the code of the pressed button, it means that the button is working properly. The code corresponding to the [1] button is 33, so the LEDs should show 33. Continue with the [2] button or any of the buttons. The code corresponding to the [2] button is 32. The [3] button - 31. Minus button - 29. Pause button - 28. When pressing the pause button, there is only one beep, with a slight delay, which is normal. Plus button - 27. Left arrow button - 26. Right arrow button - 24. Up arrow button - 23. Down arrow button - 30. Center button - 25. Menu button - 22. Power button - 21. The code is also displayed over the battery symbol on the User Interface. This helps you perform the test with the Commander at a greater distance from the Receiver. All of the buttons must pass the test, in order for the test to be considered successful. To end the test, you need to press the power button on the controller. If you are using a C2 Controller, to deactivate the functions of the Commander buttons, access the Config Menu and navigate to the IR REMOTE TEST option, then press the center button. This also enables the USE NN IR option. With older firmware versions, you need to enable this option manually, in the Config Menu, before starting the test. Now press the Commander buttons, one by one, and see if the code of the pressed button is displayed on the OLED. End the test by pressing the power button on the controller. If none of your Commander buttons are working, but its red light at the top is flashing when a button is pressed, then end the test by pressing the power button on the controller, and make sure the Receiver is properly connected to the AUX Port of the controller, then perform the test again. Now you should see the red light flashing on the Receiver as well, when a button is pressed on the Commander. Also, if none of your Commander buttons are working, and there is no red light at the top when a button is pressed, then it could be a battery issue. End the test by pressing the power button on the controller, and try replacing the batteries of the Commander with new ones, then perform the "IR Remote Test" again, to see if the problem is fixed. You can also launch the live view of your camera, or use a phone, and frame the tip of the Commander. When pressing a button on the Commander, you should see another, big, LED flashing, besides the red one you can see with the naked eye. Please note that the codes of the buttons on the early Commander models may be different from the current ones; this does not affect the operation of the system. *************** Short Links: Authorized Dealers: https://j.mp/30VpyI4 Forum - All things Panoramas: https://bit.ly/3nMCpVL Facebook: https://j.mp/3eoijLS Facebook Mecha: https://j.mp/3qqSd0e #NodalNinja #PanoramicPhotography #360Photography
