They Do It with Mirrors: Transistors 101, episode 12

Transistors 101, episode 12 They Do It with Mirrors We examine a simple two transistor current mirror, a circuit that regulates its output to have an equal current to its input. The circuit can be used to balance the currents in two parts of a larger design, or to reverse the direction of current flow (turn a current source into a current sink, or vice versa). Schematics are on the project GitHub: https://github.com/kennykb/kevins-cav... TIMELINE 0:00 Intro 0:34 What's a mirror? 2:10 Designing a mirror 5:59 Test circuit 8:29 Test at the bench 9:22 Test results; Early effect 11:32 Next steps; outro CREDITS Music: “Light Sting” Kevin MacLeod (incompetech.com) Licensed under Creative Commons: By Attribution 4.0 License http://creativecommons.org/licenses/b...
