How to set up and use your Dyson CSYS™ floor task light

How to set up and use your Dyson CSYS™ Floor task light. This is quick and easy to do as shown in our video guide. Please note, the light should never be positioned by moving the weight. Always use the horizontal arm holding the LEDs. Step 1. Stand the base on a flat surface and remove any packaging. Step 2. Insert the Vertical assembly into the base, ensuring it fits securely. Step 3. Using the provided Allen key secure the Vertical assembly in place with the larger screw. Step 4. Remove both pieces of red tape covering the electrical contacts. Step 5. Align the screw holes on the plates and press both parts together with one hand. Step 6. Loosely screw in the three screws using the provided Allen key. Step 7. Ensure the plates are aligned, then secure all three screws fully. Do not over tighten the screws. Step 8. Carefully place the light on its side, remove the magnetic retainer and plug the cord into the centre of the base. Step 9. Carefully fit the cord into the indicated groove ensuring it's not twisted. Replace the magnetic retainer, with the hole fitting directly over the end of the cord. Step 10. Remove the transit tape and all packaging from the product. Step 11. Using at least two fingers gently press the touch pad to turn on the light. Step 12. CSYS lights have touch-sensitive, continuous dimming. Adjust the level of the light you need by keeping your fingers held on the touch pad. Dyson experts are on hand to help, so leave us a comment if you'd like some advice.
