GNS3 Talks: Juniper 17.3 vSRX appliance: Import and integrate with GNS3 networks (Part 2)

This video shows you how to import a Juniper version 17.3 vSRX appliance into GNS3. Based on the feedback I have received about my previous videos, I am now showing you how to import and configure the latest version of the Juniper vSRX appliance. Steps ===== Note for LAN I have used 10.1.1.254/24 ************************ Set Password and save Login with root and no password cli edit set system root-authentication plain-text-password commit exit ************************ Housekeeping set system host-name GNS3_VSRX1 set system name-server 8.8.8.8 set system name-server 8.8.4.4 set system domain-name gns3.com set system services ssh ************************ Set IP's as required and at this stage make sure have LAN address on ge-0/0/0.0 you can ping from LAN host Set WAN as DHCP and verify address and route. set interfaces ge-0/0/1 unit 0 family inet address 10.1.1.254/24 set interfaces ge-0/0/0 unit 0 family inet dhcp-client run show interfaces terse Do NOT proceed until you have a valid WAN IP and default route so you can ping out to Internet ************************ set security zones security-zone trust interfaces ge-0/0/1.0 set security zones security-zone untrust interfaces ge-0/0/0.0 set security nat source rule-set trust-to-untrust from zone trust set security nat source rule-set trust-to-untrust to zone untrust set security nat source rule-set trust-to-untrust rule source-nat-rule match source-address 0.0.0.0/0 set security nat source rule-set trust-to-untrust rule source-nat-rule match destination-address 0.0.0.0/0 set security nat source rule-set trust-to-untrust rule source-nat-rule then source-nat interface ************************ Misc enable SSH and HTTPS (from LAN) set security zones security-zone trust interfaces ge-0/0/1.0 host-inbound-traffic system-services ping set security zones security-zone trust interfaces ge-0/0/1.0 host-inbound-traffic system-services ssh set security zones security-zone trust interfaces ge-0/0/1.0 host-inbound-traffic system-services http set security zones security-zone trust interfaces ge-0/0/1.0 host-inbound-traffic system-services https Misc enable SSH and HTTPS (from WAN) set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services http set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services https set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services ssh set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services telnet set security zones security-zone untrust interfaces ge-0/0/0.0 host-inbound-traffic system-services dhcp set system services web-management http interface ge-0/0/0.0 set system services web-management http interface ge-0/0/1.0 set system services web-management https system-generated-certificate ************************
