12" MITUTOYO "MADE IN JAPAN" OPTICAL COMPARATOR

Please check our website for photos or any other info. Thanks for stopping by! https://www.machineryvalues.com/inven... 12" MITUTOYO "MADE IN JAPAN" #PJ-H3000F SERIES VERTICAL PROJECTION BENCH TYPE OPTICAL COMPARATOR WITH FACTORY FLOOR STAND/CABINET ** BUILT-IN TWO-AXIS DIGITAL READOUT DISPLAY & DRO FOR THE SCREEN PROTRACTOR ** EXACT MACHINE MODEL: PJ-H3010FT1-200 MITUTOYO CODE: 303-994A S/N: 5L0101 NEW: 2005 SCREEN DIAMETER ............................ 12" PROTRACTOR SCREEN ROTATES .................. 360 DEG. XY RANGE (TRAVELS) ......................... 8" x 4" TABLE SIZE ................................. 16.93" x 10" EFFECTIVE AREA OF TABLE .................... 11.02" x 7.09" MAX. WORKPIECE HEIGHT ...................... 4.13" APPROX. DIMENSIONS (MACHINE) ............... 20"W x 32.5"D x 45.25"H DIMENSIONS OF THE CABINET .................. 20"W x 28"D x 26"H APPROX. MACHINE WEIGHT ..................... 398 LBS. EQUIPPED WITH: ERECT IMAGE - IMAGES PROJECTED ON THE SCREEN MOVE IN THE SAME DIRECTION AS THE "XY" STAGE FOR EFFICIENT & CONVENIENT OPERATION. LARGE PROTRACTOR SCREEN (306mm), THE SCREEN ROTATION CAN BE DIGITALLY DISPLAYED WITH A RESOLUTION OF 1' OR .01 DEGREES. HIGH ACCURACY FLOATING TABLE - BY SEPARATING AXIAL MOTION, AND STABILIZING THE XY MEASURING STAGE IN THE Z-DIRECTION, HIGH MEASURING ACCURACY HAS BEEN ACHIEVED. MITUTOYO ROTARY TABLE FOR A LARGER XY STAGE, GLASS DIAMETER IS 8". MITUTOYO CODE NO. 172-289, S/N: 400114. MITUTOYO CABINET STAND, CODE NO. 172-269, S/N: 400191. SURFACE & CONTOUR ILLUMINATION THREE POSITION LENS TURRET 5X, 10X & 20X LENS MAGNIFICATIONS ARE WITH OUR MACHINE. LENSES ARE PARFOCAL, ELIMINATING THE NEED TO REFOCUS AFTER CHANGING THE MAGNIFICATION. NEW LENS DESIGN WITH DRASTICALLY BRIGHTER & CLEARER SCREEN IMAGES DURING SURFACE ILLUMINATION. HALOGEN BULB, 24V, 150W STANDARD 1 PHASE/60 CYCLE/115 VOLT ELECTRICS SPECIAL NOTE: CALIBRATED LAST BY: COMPANY: CPI TECHNICIAN: DLW 05/01/2018 ID #: 5L0101 ** INSPECT UNDER POWER IN OUR HARRISON, N.J. WAREHOUSE ** *** EXCEPTIONAL CONDITION - WOW - STUNNING MACHINE TOOL! ***
