Lagun FTV 4L Vertical Mill 42526

MACHINERY CONSULTANTS INC 1390 W. 200 S. Salt Lake City, UT 84104 Ph: 801-531-9500 Fx: 801-531-9555 Em: nicole@machineryconsultants.com www.machineryconsultants.com We are pleased to offer, subject to prior sale and our conditions of sale, the following for your consideration: Pre-Owned Lagun Vertical Mill Model: FTV-4L Serial No: 42526 General specifications are approximate and are subject to verification. Table Working Surface: 11”x 58” Longitudinal Travel: 37 ½” Cross Travel: 15” Knee Travel: 18” Ram Travel: 22 ½” Spindle Speeds: Variable Speed 60 to 4200 RPM Spindle Taper: #40 NST w/ Quick Change Spindle Feeds: 3 Changes 3, 6 and 15 IPR Saddle & Table Feeds: 12 Changes ¾” to 36 ¼” IPR Main Drive Motor: 4 HP Electricals: 220/440 V Approx. Weight: 4,000 Lbs. Approx. Dimensions: 64” L x 84” W x 96”H Complete with: • 2 Axis Anilam DRO, Wizard 211 Mill Kit • #40 NST Tool Holders & Collets w/ Rack • Hardened & Ground Square Ways w/ Dovetail Guides • Power Feed, All 3 Axis w/ Rapid Override • Bijur Auto-Oil Lube Pump System • Coolant Pump in Flood Base Frame Condition: Excellent! Like New Finish All the Way Around. Just Released from a Research Lab. Inventory No: #9886
