Mercedes-Benz SLK | Removing The Rear Bumper

3,7,The first step for removing the rear|bumper is carried out in the trunk.|| 8,10,The trim of the rear center section|must be removed here.|| 11,18,One screw must be removed on both the|left and right sides.|| 19,35,Remove the five expansion rivets|with an assembly wedge.|| 37,46,Remove the eight expansion rivets |on the upper edge of the trim with |commercially available pliers.| 49,53,Pull out the two rubber end stops|for the trunk lid.|| 56,63,Open the service flaps|on both sides.|| 64,68,Pull out the trim from the trunk floor.||| 70,73,Switch off the ignition and|remove the key.|| 79,85,Disconnect the two electrical connectors|before taking out the rear center section.|| 86,90,These are connected to the switch for the|trunk partition and the illumination.|| 96,99,Continue behind the service flap.||| 100,104,Remove the difficult-to-access bolts|and nuts using suitable tools.|| 108,118,The position of the nuts is shown here|on the other side of the vehicle.|| 119,128,Then remove the two bolts.||| 129,132,The bumper drops down slightly|when the bolts are removed.|| 135,144,The last nut is located in the center|behind the catch for the trunk lock.|| 145,148,If the vehicle has the Parktronic|special equipment as shown here:|| 149,155,Cut the cable tie on the wiring harness|on the right-hand side.|| 156,160,Detach the connector.||| 163,169,Finally, press the grommet through the|hole to the outside.|| 169,173,Another six bolts now have to be removed|from the outside of the vehicle.|| 174,183,Two of the bolts are directly|under the bumper.|| 184,186,The vehicle lift is then no longer required.||| 188,194,The next two bolts are located in the|rear section of the fender liner.|| 195,206,Remove these bolts on both sides.||| 207,212,Detach the bumper with the help of|an assistant.|| 213,220,Note: On the right-hand side, guide the|PTS wiring harness through the hole|to the outside.| 222,226,The new bumper is installed|in reverse order.|| 227,231,After installing the outside parts, check|the gap dimension with the trunk closed.|| 232,236,Use a gap dimension gauge to measure|the dimension 'Trunk lid to bumper'.|| 237,247,The specified gap dimension is 5.0 mm|with a tolerance of +1.5 and -1.0.|| 248,252,In this case, the gap dimension is correct.||| 253,260,Finally, install the remaining parts|in the trunk.||
