Program: https://emc4b.com/szkolenia/emc-for-a... Register: https://emc4b.com/szkolenia/zapisy-na... COURSE LANGUAGE: ENGLISH Workshop date: November 17-18, 2022 Time schedule: 9:00 AM - 5:00 PM (both days) The workshop is taking place at the Łukasiewicz Research Network - Institute of Innovative Technologies EMAG AT THE EMC LAB! The aim of the workshop is to understand how to design and test electronic devices for vehicles in accordance with EMC (Electromagnetic Compatibility) requirements. Workshop for electronics designers and testers solving EMC problems in the automotive industry. Training course at the EMC laboratory, practical, interactive. Learn about requirements, testing stations, test preparation and techniques, PCB and system design recommendations. Training program (eng.) Day 1/2 EMC requirements for Automotive What it is EMC? How to scheduce EMC testing in project plan – v-shape Testing EMC for Automotive EMC Standards in automotive: ISO 10605, ISO 7637 – 2, ISO 7637 – 2, ISO 7637-3, ISO 16750 – 2, ISO 11452 – 2, ISO 11452 – 4. CISPR 25 Emission radiated and conducted (ALE, LISN, TEM, STRIPLINE) Immunity conducted and radiated Testing equipment Test setup EMC test plan Preparing to testing (equipment, load, harness) Results interpretation Design electronics – specific Automotive industry Important phenomena and concepts Electromagnetic Transmission line Inductance and capacitance Impedance Coupling paths Filtering Overvoltage ESD protection Day 2/2 PCB Design – schematic, layout PCB Grounding, slots, reference planes Design rules – schematic and layout Schematic Layout PCB Power plans Stack-up Routing Via Components Cmmunication (LVDS, CAN) Ic decoupling Crosstalk DC/DC Converters EMI aspects, Different aplications similar EMI problems, snubbers Signal Integrity High Speed design Termination Jitter Eye diagram Pre/de-empahis Equalisation System compatibility Shielding Harness Troubleshooting Harmonics od digital signals Edges Scope and probes in EMC BCI ESD protection Immunity sperimposed a.c. voltage Load dump ISO 7637-2 pulses ISO 7637-3 pulses Design Guidelines (Good and Bad) Questions and answers
