Inductive Couplers by SMW

With contactless inductive coupler systems, SMW now offers the technology to transmit energy and data, contact-free, between stationary and moving components via an air gap. SMW's new full product range includes standard couplers as well as couplers for complex customer-specific designs. Standard couplers are axial couplers with threaded fasteners commonly used in sensor technology. With their method of fixing these are easy to install and are quickly integrated, thanks to their plug & play functionality. The built-in LED display notifies the user of the system's status at all times. Radial couplers for rotary applications are available with diameters of up to 280 mm and large internal diameters. An inductive coupler system consists of a stationary coupler and a movable mobile coupler. By using such couplers in a system, power can be supplied to sensors, actuators or control components and at the same time, any necessary data signals can be transmitted bidirectionally in analog or digital form. Transparent coupling of entire fieldbuses such as CAN or Profibus is also possible. Of particular note is the ability to transfer up to 1500 W of power at high bandwidths for operating actuators. Inductive transmission technology is completely wear- and maintenance-free and replaces traditional transmission methods using cables, contacts or slip rings. In automation applications especially, cables and contacts are subject to very high wear and tear and this can, for example, lead to machine downtime due to broken cables. Inductive coupler systems are protected to IP 67 and therefore can be used in harsh, demanding environmental conditions; they are also insensitive to vibration.
