Teardown of InfinityLab InstantCharger 100W GaN Charger (2A2C)

You can buy it on Amazon: https://amzn.to/3rmTRBf If you wanna buy the tester of POWER-Z, you can visit our Amazon store: https://www.amazon.com/s?me=A31UM8SRX... Introduction --------------------------------------------------------------- HARMAN InfinityLab is a well-known digital accessories brand. And today, we got a InfinityLab 100W 2A2C GaN charger, which has a smaller size and better performance. Let's take it apart. Bill of materials (BOM) ------------------------------------------ Varistor: STE 10D511K Safety X2 Capacitor: WQC, 0.33μF Bridge Rectifier: Pingwei TBMR610 PFC Boost Controller: NXP TEA19162 GaN FET for PFC: GaN Systems GS-065-011-1-L PFC Rectifier: Pingwei ES5JGR High-voltage Capacitor (PFC filtering): JSH Master Control Chip: TEA19161T, TEA19162 LLC MOSFET: SemiHow HCFL65R210 SMD Y Capacitor: TRX TMY1102M Synchronous Rectifier: Hunteck HGN098N10AL Secondary Rectifier Controller: NXP TEA1995T Solid Capacitor: JSH Protocol Chip: Weltrend WT6636F Buck Converter: Toll Microelectronic TMI2286D MOSFET (voltage drop): Hunteck HTM200P03 VBUS MOSFET: ARK AKF30N5P0S Buck Controller (USB-A): Southchip SC8002 Buck MOSFET: Huayi HY1503C1 Charging Controller IC (USB-A): SMEI CW3005F Chapter ---------------------------------- 0:00 Intro 1:06 Test 1:51 Teardown 2:14 Analysis 7:56 Summary For more details. You can visit our website: https://www.chargerlab.com SOCIALS: Instagram：  / chargerlabs   Facebook：  / chargerlab   Twitter：  / chargerlab   For Business Inquiries: info@chargerlab.com
