Learn how to check your SOLIDWORKS design for Manufacturability using DFMXpress

Rapidly identify design areas that may cause fabrication issues or raise production costs using SOLIDWORKS 3D CAD, increasing the speed of your design process, enhancing productivity and saving time and money. SOLIDWORKS DFMXpress analysis tool confirms the manufacturability of parts designed with SOLIDWORKS. You can use DFMXpress to detect design areas that could potentially cause problems during fabrication or increase production costs, and rapidly review parts with mill, drill, turning, sheet metal and injection molding requirements. The features of DFMXpress include: • Drilled hole inspections—hole diameter-to-depth ratio, flat bottoms on holes, perpendicular entry surfaces, holes that intersect internal cavities, partial holes, tolerance tests • Milled feature inspections—deep pouches and slots, inaccessible features, sharp internal corners, fillets on external edges • Turned part inspections—minimum corner radii for turned parts, bore relief for turned parts • Sheet metal inspections—hole diameters vs. available tooling, hole-to-edge distance, hole spacing, bend radii • Regular hole size inspections—check hole vs. available tooling • Injection moulding inspections—maximum and minimum wall checks • Checks for the draft, undercuts, and advanced thickness analysis is also incorporated in SOLIDWORKS and can be located by clicking the “Evaluate” tab • Simulation of plastic mould filling is accessible in SOLIDWORKS Plastics Logical Solutions Limited is a leading Authorized reseller for SOLIDWORKS Software in Hyderabad, Telangana & Andhra Pradesh. Logical Solutions offers a complete portfolio of SOLIDWORKS 3D CAD software tools for Design, Analysis, Product Data Management, Technical Communications, and Electrical Design. For more details visit: http://www.logicalsolutions.in/products http://www.logicalsolutions.in/services For training visit: http://www.logicalsolutions.in/training Contact: 9133445956
