FreeCAD Scale Object - How To Scale Objects - Scale In FreeCAD

You can scale objects in FreeCAD with the Draft workbench! This model consists of multiple bodies, so i created a stepfile and saved it as a FreeCAD format. Selecting multiple bodies in the original file gave me some problems with scaling. First you have to go to the Draft workbench. Then click on the 'Scale' button. It's recommended to select your objects first and then click the button. Then enter the coordinates where you want to position the scaled model. I enter 0,0,0 here. I didn't use the 'Continue' and 'Copy' feature here, because i couldn't notice the difference. After entering the right coordinates, click on 'Enter point'. Selecting 'Uniform scaling' will result in the same X,Y and Z scaling factors at once to keep original proportions. Selecting 'Working plane orientation' gave me some wrong proportions, so i leave it unchecked. 'Pick from/to points' is to scale along specific points. I prefer to enter an exact factor. Then you have the choice between creating a clone, modify the original or creating a copy. If you create a clone, all selected bodies you scaled, will be one object afte scaling. You can also edit the scale factor later with a clone. With modify the original option, you scale the original model and there won't be a copy of it after scaling. Creating a copy will copy all selected bodies to a new scaled object. This video was recorded in the stable release of FreeCAD 0.18 (2019-04-04). https://www.freecadweb.org 👍 Thanks for watching the video FreeCAD Scale Object - How To Scale Objects - Scale In FreeCAD 🎧 My Spotify playlists: https://open.spotify.com/user/schippe... ⚠ There are affiliate links in this description. Affiliate means that when you buy something after clicking on one of these links in this description, i will receive a commission each time you buy something. By shopping through these links, you don't have any extra costs. 🌐 https://3dpartsforyou.com/affiliate-s... 🔴 Products i use that you can buy on eBay (affiliate links) 🕛 Buy LaMetric TIME on eBay: https://ebay.us/cJpq97 ♻ Buy PolyTerra™ PLA on eBay: https://ebay.us/Y3CYqw ⛏ Buy Modifi3D on eBay: https://ebay.us/DB3uOs 📱 Buy Samsung Galaxy S10 Plus on eBay: https://ebay.us/me5CJM 🎞 Buy GoPro HERO 10 (and accessories) on eBay: https://ebay.us/IppoS1 🕹 Buy TELESIN 80M Bluetooth Remote Control For GoPro on eBay: https://ebay.us/7nfNAS 📌 Buy Flexible Clamp Mount For GoPro on eBay: https://ebay.us/xAWWRr 🔴 Products i use that you can buy on AliExpress (affiliate links) 📱 Buy Samsung Galaxy S10 Plus on AliExpress: https://s.click.aliexpress.com/e/_DDY... 🕹 Buy TELESIN 80M Bluetooth Remote Control For GoPro on AliExpress: https://s.click.aliexpress.com/e/_DlR... 📌 Buy Flexible Clamp Mount For GoPro on AliExpress: https://s.click.aliexpress.com/e/_DEy... 🏬 AliExpress (affiliate links) 🔴 Filament: https://s.click.aliexpress.com/e/_ALIBnp ⚙ 3D Printers: https://s.click.aliexpress.com/e/_9gycUJ ✂ 3D Print Tools: https://s.click.aliexpress.com/e/_AYg7aX 🏬 eBay (affiliate links) 🔴 Filament: https://ebay.us/HbEQCQ ⚙ 3D Printers: https://ebay.us/7qcK6B ✂ 3D Print Tools: https://ebay.us/1PWa1Z 🏬 Gearbest (affiliate links) 🔴 Filament: https://www.gearbest.com/sale/filamen... ⚙ 3D Printers: https://www.gearbest.com/sale/3d-prin... ✂ 3D Print Tools: https://www.gearbest.com/sale/3d-prin... 🌐 My website: https://www.3dpartsforyou.com 👉 Subscribe to my channel AllVisuals4U:    / @allvisuals4u   👉 All playlists of this channel:    / @allvisuals4u   ⚡ Subscribe to my short format channel AllVisuals4U Shorts:    / @allvisuals4ushorts   ⚡ All playlists of this channel:    / @allvisuals4ushorts   #AllVisuals4U #FreeCAD #Scale #Object #Design Music: Sunrise Drive - South London HiFi h   • 🎵 Sunrise Drive - South London HiFi 🎧 No C...   YouTube Audio Library (0:00-2:31) Music: Eyeliner - Underbelly    • Underbelly - Eyeliner   YouTube Audio Library (2:31-4:51)
