How to Use The Recording Function on The Fluke ScopeMeter® Portable Oscilloscope

http://bit.ly/2xabqIi In this video, learn how to use the Fluke ScopeMeter® TrendPlot™ Function. To access the TrendPlot Function on a Fluke ScopeMeter® Portable Oscilloscope, 1. Select the measurements you want the Fluke ScopeMeter® to record. Press the "Scope" button. 2. Press the F2 button to view the selection of measurements and choose whichever measurements are most relevant to you 3. Once your measurements have been chosen, press "ENTER". 4. Press the "Recording" button to begin recording your selected measurements. 5. A TrendPlot™ option will appear on the screen. Press "Enter" to display the measurement readings on the ScopeMeter® interface. The Fluke 190 series combines the power of a high performance oscilloscope, multimeter and paperless recorder in an easy to use test tool you will come to rely on in the field. The TrendPlot™ function in the Fluke ScopeMeter® test tool helps find intermittent faults by: Plotting minimum and maximum peak values and average over time up to 22 days Plotting any combination of voltages, amps, temperature, frequency and phase for all four inputs, all with time and date stamp to pinpoint faults. For more information on the Fluke 190 Series II ScopeMeter®, visit the Fluke website here: http://bit.ly/2xabqIi
