Structural Engineering & Construction Situation 14 (PH)

PAST BOARD EXAM PROBLEMS Structural Engineering & Construction Situation 14 The line of action of the force P coincides with the axis of the angle which is at distance a=29mm from the back of the connected length. Properties of one angle: 100x100x8mm A = 1770 mm2 Yield stress, Fy = 248 MPa Allow weld shear stress, Fvw = 93 Mpa 1. Determine the max. tensile capacity of the angle. (263376 N) 2. Determine the value of L2 using 6mm fillet weld. (474 mm); and 3. What is the value of L2 when a weld size of 5mm is added at the end of the angle? (294.88 mm. Credits: 1. Intro Template:    • (FREE) 2D Square Intro (60 fps - No Text) ...   2. Music: 2.1 Driven to Success by Scott Holmes, Source: http://www.freemusicarchive.org 2.2 Instrumental (Guitar) by Carl Ernest Tayag, check his channel:    / @ninja35ful   3. Reference for the problem: Civil Engineering Reference for Licensure Examination, Volume 4, 1st Edition by DIT Gillesania (GERTC Review). Comment your suggestions or questions here. Thanks for watching! Subscribe now for more videos and click the bell icon for notifications. God bless! :) #SEC #CEBox #CivilEngineering #Engineering #ceboardexam #boardexam #prc #review #CivilEngineeringLicensureExam #structuralengineering #stem #engineeringlife #stemlife
