Boss RC-505 & FCB1010 Midi Controller (Part 1) скачать в хорошем качестве

Boss RC-505 & FCB1010 Midi Controller (Part 1)

NOTE (March 2019): In the meantime UNO has released a dedicated eprom for the rc-505 control called fcb505. This gives a lot more options (12 switches in stompbox mode and 2 expression pedals can be used), only one bank is available though and everything is fixed on the fcb. Configuration has to be done on the RC. Check it out: https://www.fcb1010.eu/fcb505.html Gear used in the video: Boss RC-505 - https://www.thomann.de/gb/boss_rc_505... Behringer FCB1010 - https://www.thomann.de/gb/behringer_f... 5 Pin Midi Cable - https://www.thomann.de/gb/the_sssnake... Especially for guitar, bass and other players who need their hands to play an instrument. This 3 part video explains how to configure the Boss uRC-505 so it can be controlled via a FCB1010 Midi controller. Each of the 5 channels will get a Rec-Overdub - play button and an undo but other configurations are possible. The FCB1010 is equiped with a UNO chip because StompBox mode is required. You can get more info on this on www.fcb1010.eu A list of the Midi parameters on the RC-505: RC-505 SW: Version 2.0 Midi Channel used is channel 1 System config of the RC-505: Sys:MIDI Rx Ch 1 Sys:MIDI Omni ON Sys:MIDI Tx Ch Rx (not used) Sys:MIDI Sync AUTO Sys:MIDI SyncSrc USB(AUTO) Sys:MIDI PC Out OFF Phrase Memory Settings Assign1 Switch ON Assign1 Source #CC21 Assign1 Src Mode MOMENT Assign1 Target TR1 REC/PLAY Assign1TargetMin ---------------- Assign1TargetMax ---------------- Assign2 Switch ON Assign2 Source #CC22 Assign2 Src Mode MOMENT Assign2 Target TR2 REC/PLAY Assign2 TargetMin ---------------- Assign1TargetMax ---------------- etc.
