Video tutorial on how to program ramp and soak controller

This is a video tutorial on how to program our MTC-P ramp and soak controller, klin temperature controller, profile controller . specific program is depicted as image to help us explain how to proceed with the programming Segment 1)The system starts at 0 degree and takes 1 hour from 0 degree to 300 degree, SV1.1 =300, tr1.1=1.0, ot1.1=100 Segment 2)Keep the temperature at 300 degree for 0.5 hour, SV1.2=300, tr1.2=0.5, ot1.2=100 Segment 3)System temperature drops to 220 degree within 0.7 hour, SV1.3=220, tr1.3=0.7, ot1.3=100 Segment 4) System temperature maintain at 220 degree for 1.5 hour, SV1.4=220, tr1.4=1.5, ot1.4=100 Segment 5) Temperature goes up to 250 degree within 0.3 hour SV1.5=250, tr1.5=0.3, ot1.5=100 Since the program with only 5 segments, the way to end the program is to set the ot1.6 as "0" , SV1.6 and tr1.6 can be any value. the way to end the program is set the following ot parameter as "0"
