2 DOF SEATMMOVER FINAL TEST - ARUDINO - IBT-2 - 24 VOLT WHEELCHAIR MOTOR DIY SETUP

FINAL TEST OF THE 24 volt DIY motion simulator using the Arduino, IBT-2, 24 volt converters and 24 volt Jazzy Wheelchair motors - I show you how to adust SMC3 and simtools! It's finally ready to see how many amps this seatmover will take and if the 24volt 25 amp converters can handle the load. . Take a look if you consider upgrading your static rig into a motion seatmover or more! 2 DOF motion simulator seatmover now has bigger motors mounted for more power! 24VDC Jazzy wheelchair motors mounted to this 2 degree of freedom motion simulator.. This video details the electrical wiring between the Arduino, the IBT-2 motor controllers, Hall effect potentiometers and the 24Volt converters. 00:00 start 03:00 Super Thank you 5:00 first test at minimal settings 10:00 now cranking it up in simtools 20:00 lets crank up the settings in game manager 24:00 Final thoughts and upcoming design modifications Should any of you wish to help the refugees from Ukraine here are three organizations which are on site and assisting. SAVE THE CHILDREN https://www.savethechildren.org/ UNICEF https://www.unicefusa.org/stories/uni... Church in Need https://www.churchinneed.org/ukraine-... Music by my friend RacerXTZ ____ Amazon link for 24VDC 25amp power supply. 24V 25A 600W LED Driver Switching Power Supply （SMPS） Monitoring Power Supply Industrial Power Transformer 110/220VAC-DC24V https://www.amazon.com/gp/product/B07... Jazzy Wheelchair motors on Ebay.. Since Ebay links change all the time, just search for Jazzy Wheelchair motors. There are a few different kinds. Just look for the ones in the video for reference. They cost me $65 for both plus $20 shipping. 50:1 12volt motors just search Ebay for GEAR MOTOR 12 VOLT GREAT FOR SAWMILL/CRAB POT PULL/FEED/SIMULATOR 75-80RPM 50:1 (sold by PGSAW in Canada) Hall Effect Potentiometers DIGI-Key and others PN 987-1392-ND https://www.digikey.co.uk/en/products... Arduino UNO R3 - amazon. I have also used the cheaper ELEGOO clone. https://www.amazon.com/Arduino-A00006... IBT-2 motor controllers up to 43amps (which is a lot!) https://www.amazon.com/dp/B00WSN98DC?... other motor controllers you could consider using are JRK12V12 or Sabertooth but I use IBT-2's XSIMULATOR forum - Info specifically for arduino/IBT-2 for 1 to 3 Motors. You can use up to three motors per arduino. But you each motor needs it's own IBT-2 controller. https://www.xsimulator.net/community/... DMAX motion sim build posts on XSimulator https://www.xsimulator.net/community/...
