How to Connect Color Changing LED Strip Light to RGB Wireless Controller and Transformer

This video has two part: 1. It will show you how to set up the color changing (RGB) strip light with the wireless controller, receiver and the transformer. 2. It will explain how to match the wireless controller and receiver in 3 simple steps. Products in the video can be found on www.GLLEDLLC.com: -LED strip light: High Bright 5050-60 SMD RGB-300, 12V -Transformer: LED Transformer 100W 12VDC -H, Waterproof -Wireless Controller: LED Wall Mount Change Color RGBW Controller, 3 zone -- RF/WIFI -Mini transformer: Controller Mini Power supply 12V 1-9W -Receiver: RGBW RF/WIFI Receiver 8A 4CH Product from third party: -Regular size plastic junction box (Home Depot) Description of the product: a.Wireless controller is a sender, it has to work with a receiver to receive signal. And the receiver will connect with the strip light. Therefore, you can place the wireless controller anywhere within 50ft from the receiver. This function allow user to set up different zones with one controller. For example the controller shown in the video can set up 3 different zones, all you need is to match the zone with the receiver. This video will also work with other wireless controller products we have. For hard wire controller, you will connect strip light directly to the controller. b.Mini Transformer is a big move for wall mount controller. The traditional way to connect power for low voltage controller is to wire it back to the big transformer. With this mini transformer, you can attach it with the controller and fit well in regular size junction box. It's much more simple and clean. c.Plastic Junction box does not block as much signal send out from wireless controller as the metal box. So you can make the most use of the RF or WIFI signal distance range. We highly recommend the plastic junction box. Important Reminder: 1.Make sure the strip light and the transformer is the same voltage. If not, it might ruin the product. 2.Connect power plug to the AC INPUT as it mark on the transformer, and connect output side to low voltage LED.
