How does Tripod Turnstile Work? 2023 Best Guidance скачать в хорошем качестве

How does Tripod Turnstile Work? 2023 Best Guidance

More info:https://www.macrosafegates.com/one-wa... The scenic spot tripod turnstile movement is mainly composed of a main shaft, an electromagnet, a toothed cam, a positioning cam, a travel switch, a damper, a spring, and a drop rod device. When the tripod turnstile drive board (hereinafter referred to as the drive board) receives the gate opening signal, one relay is closed, and the corresponding electromagnet is turned on, which promotes the contraction of the lock arm and avoids blocking the toothed cam. At this time, pedestrians only need to push Then the lever can touch the screw along the distance switch which is released from the determined blockage, and the former gives a signal to the drive board, indicating that the pedestrian has passed, and the action is completed. The rod (including the bearing connected with it), the damper, and the spring start to work, buffering the accumulated elastic potential energy until the lock arm interacts with the toothed cam again. The rod drop device is installed on the bearing seat. Once the power is cut off, the brake rod will automatically drop to leave an escape channel. Modern smart scenic spots are the trend of future development. People's desire for spiritual pursuit is constantly increasing, and the potential of the tourism market is constantly growing. In the future, tourism consumption will account for a large proportion of people's lives. Therefore, it is very prescient for scenic spots to occupy the market through the transformation of smart scenic spots early.
