Chop Saw Automation (Arduino Powered)

Cutting thousands of these small pieces of aluminum with the help of an Arduino and a couple of stepper motors. They will eventually become brackets to fasten computer monitors to metal enclosures. Here's a quick lil vid on how I did that. The brackets measure .750" x .547" x .125", tolerance is quite decent at + or - .002" I tried to keep the code as simple as possible because I'm not much of a programmer and didn't want to spend too much time on it. The loop is triggered by the Arduino reset button. The linear actuator is controlled by an h-bridge with 4 simple switches activated by one of the steppers. Music by Gerardo Larios and yours truly. #automation #arduino Here's the code for you (us) nerds: include Stepper.h define stp 2 define dir 3 define MS1 4 define MS2 5 define EN 6 const int stepsPerRevolution = 800; Stepper myStepper(stepsPerRevolution, 2, 3); Stepper myStepper2(stepsPerRevolution, 8, 9); void setup() { myStepper.setSpeed(200); myStepper2.setSpeed(800); pinMode(stp, OUTPUT); pinMode(dir, OUTPUT); pinMode(MS1, OUTPUT); pinMode(MS2, OUTPUT); pinMode(EN, OUTPUT); } void loop() { digitalWrite(EN, LOW); myStepper.step(-9500); delay(100); myStepper2.step(-1600); delay(5000); myStepper2.step(1600); delay(100); myStepper2.step(1600); delay(5000); myStepper2.step(-1600); delay(100); } Thanks for watching! More videos on the way so please subscribe!
