1.3MP SWIR camera with IMX990 - Goldeye G-130

Product focus: Goldeye VSWIR camera with IMX990 InGaAs sensor https://axiomoptics.com/low-light-cam... Discover 4 new Goldeye models with the SenSWIR-InGaAs sensors by Sony (IMX990 and IMX991). 1.3MP resolution and VGA resolution with 5µm pitch (smallest pixel pitch in the industry for an InGaAs sensor) VIS-SWIR sensitivity with high QE from 400 to 1700nm unlocks many applications Thermoelectric cooling TEC1 for optimal image quality GigE Vision and CameraLink interfaces Main features: Integrated correction data sets, compensation of sensor inhomogeneity and underlying structures (non-uniformity correction – NUC) Defect pixel correction Background correction Automated and manual sensor temperature management via TEC features Temperature status indicator Automatic exposure time control Gain (analog) I/O configuration and trigger control Stream hold (deferred image output) Storable user sets Firmware update in the field Region of interest (ROI) control, look-up table (LUT) support, as well as various auto features Perfectly connected – thanks to powerful software Have you heard of Vimba, our future-proof and platform independent SDK (software development kit)? Thanks to our in-house software you can easily integrate Goldeye cameras with GigE Vision interface into any system and manage them centrally. Vimba runs on Windows, Linux, and Linux for ARM. With Vimba, you can acquire images and control your Allied Vision camera instantly, program complex vision applications or connect to third-party libraries. Improvements with SenSWIR sensor technology by Sony Visible spectral range extension (400nm – 1700nm) Sony SenSWIR InGaAs sensors are designed with a very thin Indium Phosphide (InP) layer enabling visible light to pass through to the sensitive InGaAs layer. There are already InGaAs sensors available on the market with visible light extension, but Sony is the first manufacturer who managed to keep the quantum efficiency over the full spectral range at a relative high level ( over 50%). In some applications (e.g. spectral imaging, surveillance) this can help to reduce system costs as only a single camera needs to be used. Higher inspection precision (5µm pixel pitch) By using Copper-to-Copper connections between the indium-gallium-arsenide (InGaAs) photodiode layer and the silicon readout circuit layer instead of Indium bumps, much smaller pixel sizes of only 5µm² can be realized. This enables imaging with high spatial resolution to reveal smaller object details. High image homogeneity Sony SenSWIR sensors are the first sensors we have integrated into the Goldeye camera series with digital outputs. Previous analog sensors require external ADCs resulting in the typical visible vertical striped that are corrected by our NUC. ​​​​​​ In addition, the high image homogeneity of Sony SenSWIR sensors is supported by the Copper-to-Copper connections, that Sony is using in their stacked design, to connect the InGaAs layer with the Silicon Readout IC. They ensure a much more reliable and uniform connection between the two layers vs. existing solutions using Indium bumps. Axiom Optics Inc is a distributor of specialized cameras and optical instrumentation located in Somerville, MA, USA. Visit our website www.axiomoptics.com Contact us at info@axiomoptics.com or (617) 221-6636.
