2D Rigid Body Equilibrium – Advanced Pulley and Beam Example | Engineering Statics Tutorial

Welcome back to the second session on 2D rigid body equilibrium in this Engineering Statics series! 🚧 In this lecture, we go beyond simple examples and explore a more advanced setup involving: A beam connected by a hinge and a cable going through a pulley. Force analysis using a detailed free body diagram (FBD). Application of equilibrium equations: ∑Fx = 0, ∑Fy = 0, and ∑M = 0. A deep dive into internal forces, reaction components, and tension in cables. A real-world feel to statics through careful reasoning about smooth pulleys, distributed loads, and reaction direction assumptions. By the end of this session, you’ll have a clear understanding of how to analyze a 2D rigid body under multiple supports and loads. Perfect for engineering students and educators looking to reinforce or test their understanding. 🔧 Stay tuned for the upcoming 3D supports and equilibrium analysis sessions! #EngineeringStatics #RigidBodyEquilibrium #FreeBodyDiagram #PulleySystem #StaticsTutorial #Mechanics #EngineeringEducation #StructuralAnalysis #2DStatics #MomentCalculation
