SOLIDWORKS At Home: Sketch Pictures and Style Splines

In this series of SOLIDWORKS At Home, Sean designs a sheath for his fancy new chef knife to print on his 3D printer. For part 1, Sean covers the use of the Sketch Picture tool to design around a photo of the knife and the use of the Style Spline (Bezier and B-spline) to capture its natural curves. Keep an eye out for part 2 that will cover splitting the body in two to aid in 3D printing, using multi-body part design to create a swivel lock to keep the blade in the sheath, and setting up the sweep feature. Timestamps: 0:00 - Introduction 0:31 - Starting the Sketch Picture 2:14 - Starting the Style Splines 4:00 - Evaluating the Spline 4:52 - Converting a Bezier Spline into a 3rd Degree B-Spline (but still under the Style Spline tool) 5:30 - Offsetting (with Offset Entities) and minimum radius of curvature issues For more information on SOLIDWORKS: https://hawkridgesys.com/solidworks For more information on 3D Printers: https://hawkridgesys.com/3d-printing Technical Support Knowledgebase: https://support.hawkridgesys.com/ Music credits: Song: "You Are Never Alone" Artist: DJ Quads   / djquads
