5 Litre Liquid Filling Machine - PB5000 Volumetric Filling Machine - Universal Filling Machines

Suitable for filling containers from 500ml to 5 litres with corrosive liquids such as Bleaches, Acids and Alkalines, the PB5000 semi-automatic, volumetric filling machine is designed for ease of use, while maximising production outputs on difficult products. Glass metering cylinders and PVC contact parts enable to the PB5000 to withstand such liquids and perform just as well as any other Universal Filling Machine. Simple to set up, adjust and operate, the PB5000 has a small footprint and is mounted to heavy-duty castors, allowing it to be sited wherever suits the user best. All that's required to power the PB5000 is an adequate supply of clean and dry compressed air. Liquids can be supplied to the PB5000 from any floor-level container via it's feed pipe system. Available with either 1 or 2 filling heads, the PB5000 can be specified to include a secondary fill speed setting which reduces the fill speed at the end of each filling cycle to prevent liquid splash-out from the neck. Additionally, a multi-dose counter and 'Wander Nozzle' may also be specified for filling volumes of up to 20 litres. The PB5000 volumetric filling machine is designed to handle acids, alkalines and bleaches. As a result, the contact parts are made from glass & PVC because even 316 stainless steel cannot withstand such liquids. The transparent metering cylinders fitted to the PB5000 enable you to see the liquid being displaced by the movement of the piston and actuator assembly. As the piston rises, liquid is forced through the metering valve, to the filling nozzles. When filling is complete, the metering valve switches over, to only allow liquid to enter the metering from the intake hoses. Momentarily later, the actuator starts to draw the piston back, drawing fresh liquid in to the metering cylinders for the next cycle. This particular model of liquid filling machine is a 2-head volumetric filler, which means it fills 2 containers at the same time. As the video shows, a single pneumatic actuator controls both pistons, to ensure fill volume consistency.  For more information, visit our website: www.universalfilling.com Or call +44 (0)1233 643666 #liquidfillingmachine #liquidfillingmachinenozzle #liquidfillingmachinesemiautomatic #liquidfillingmachinebottle #bottlefillingline #bottlefiller #bottlefillingmachines #universalfillingmachinecompany Follow us on LinkedIn: https://bit.ly/3hRDqrQ Attributions: httpswww.bensound.com http://www.videezy.com
