SCS - A Minute with Miranda - Testing ESD Footwear

Welcome back to "A Minute with Miranda." This week we will be covering how to test ESD footwear entering an ESD Protected Area (EPA). Per the ESD Handbook ESD TR20.20, A system test of the footwear in combination with the existing or proposed flooring materials in the plant should be made to ensure that the criteria for the facility are met. When using a footwear checker it is important to make sure the upper and lower resistance limits of the checker match the user’s requirements. When testing the footwear should test within the range of 1 x 10^6 to 1 x 10^8 ohms. Heel, sole and toe grounders should be worn on both feet to ensure effective use. They should be worn by all personnel and visitors within an ESD controlled area. If worn improperly, the heel, sole and toe grounders become ineffective. ESD footwear should be tested daily before use within an ESD Protected Area (EPA). View the full range of SCS ESD Footwear: https://staticcontrol.descoindustries... For more information, contact SCS: E-Mail: Service@StaticControl.com Phone: (919) 718-0000 Website: http://StaticControl.com ©2019 SCS is a brand of DESCO INDUSTRIES INC
