Mazak Integrex J-200

The INTEGREX j-200 is a compact machine designed for large workpieces - maximum machining size is Φ 500 mm (Φ 19.69") and maximum machining length is 500 mm (19.69"). Additionally, a large machining area is provided thanks to long strokes: X axis: 450 mm (17.72"), Y-axis: 200 mm(7.87"), Z-axis: 550 mm(21.65"), B-axis indexing range: 220° and C-axis: 360°. The orthogonal Y-axis machine construction is the same as INTEGREX i-150 and INTEGREX e-series and allows face milling, end milling, and drilling to be performed in the large machining area without C-axis indexing thanks to long Y-axis stroke: 200 mm(7.87")(±100 mm(3.94")).
