Technique #2: Select the optimal combining method

Making group delay measurements on frequency converting devices with an embedded LO is a challenging task. This series of videos will show how those measurements can be progressively improved through a series of 10 steps. The instrument utilized for these measurements is the ZNA vector network analyzer from Rohde & Schwarz with option ZNA-K9, which addresses a two tone group delay measurement technique. This second video will address the different ways of optimally combining the two-tone signal used for the group delay measurement. Download the resources mentioned in the video: GPIB Scripts: https://cloud.rs-us.net/index.php/s/E... For the Group Delay Measurements on Frequency Converting Devices Application Note https://scdn.rohde-schwarz.com/ur/pws... ZNA Application Cards including Using the GPIB Explorer on ZNA: https://cloud.rs-us.net/index.php/s/n...
