Making new video cables: Commodore VIC-20 composite [TCE

A video showing how I like to make composite video & audio cables for the VIC-20. Happy to hear constructive criticism, feedback and (as always) corrections. The VIC uses a 5-pin DIN and outputs a composite video signal on pins 4 & 5, mono audio on pin 3 and ground on pin 2. Note that there is a difference in the video signal on pins 4 & 5 on older VICs: pin 4 is the "video low" output and pin 5 is the "video high" output. The difference is that the "video low" output goes via an L-pad attenuator which drops the voltage level to about 60% of the "video high" output (according to the schematic). So it's safer to just use pin 5 (I think, according to other cables) - definitely don't connect pins 4 & 5 in the DIN plug if you want to maintain compatibility with all possible VICs. I like to use stereo audio cables, so I just tie the L & R wires together into the same pin 3. Finally, tie all three ground wires together into pin 2. As the VIC chip (6560 or 6561) outputs separate chroma & luma, it's also possible to use pins 4 & 5 to output an S-video output (not covered in this video). As an alternative, check out Sven's A/V adaptor board: https://github.com/svenpetersen1965/V... Parts used: [1] a 3m 3xRCA A/V cable (yellow/red/white) - I get these in bulk from Aliexpress so I can cut in half and make two 1.5m cables, [2] a 5-pin DIN plug (or jack) - I'm using a Neutrik NYS322G (Element 14 order code 1855739), [3] glued 8mm heat shrink (Jaycar code WH5642), [4] clear 3mm heat shrink (Jaycar code WH5552), [5] solder flux paste - I'm using MG Chemicals 8342-50G (Element 14 order code 3018421 ... or AU$7 cheaper code 301842101). Digirule 2U: https://bradsprojects.com/digirule2/ #Commodore #VIC20
