Mounting of Quadro concealed full extension runners: Do-It-Yourself with Hettich

One part of mounting Quadro runners to wooden drawers is fixing the Quadro catches to the panel under the drawer using two screws. If no pre-drilled hole line is provided in the furniture cabinet, you may mark the positions for drilling the holes. Always allow a space of 6 mm from the front edge of the mounting surface to the carcase edge. This produces a spacing of 37 mm for the front-most drill hole which is also the standard spacing for hole lines. Now push the drawer into the runners. The catches automatically lock the drawer onto the Quadro for a secure fit. Unlatching the drawer and removing it from the runners is just as easy. Without the need for tools, an adjustment wheel now allows you to correct front-panel height by up to 2 mm, to give you perfect, neat gap alignment. For more information, visit http://www.hettich.com
