ASL Platform Selection Drone Mapping

www.AirShotLive.com sales@airshotlive,com 262-346-3388 ASL Platform Selection Drone Mapping For efficient large-area mapping at 94 meters AGL, using 80% front and 70% side overlap, the Matrice 300/350 RTK with the Zenmuse P1 payload is the most efficient option in acres per hour. It is followed by the Matrice 4 Enterprise (M4E) and then the Mavic 3 Enterprise (M3E). This superior efficiency of the Matrice models is due to better camera sensors, quicker shooting intervals, and higher flight speeds. The provided text is a performance comparison table of three DJI mapping drones: the Mavic 3E, the Matrice 4E, and the Matrice 300/350 RTK with the P1 camera. The comparison highlights key features: Sensor: The M300/350 + P1 has the highest resolution with a 45 MP Full-Frame CMOS, while the Mavic 3E and Matrice 4E have a 20 MP, 4/3 CMOS sensor. Speed: The M300/350 is the fastest (approx. 23 m/s or 51 mph), followed by the Matrice 4E (21 m/s or 47 mph), and the Mavic 3E (15 m/s or 33.5 mph). Shooting Interval: The Matrice 4E has the fastest interval at 0.5 seconds. Ground Sample Distance (GSD): The M300/350 + P1 offers the best GSD at approx. 1.7 cm, compared to approx. 2.5 cm for the other two models (at 94m AGL). Mapping Efficiency: The M300/350 + P1 is rated "Best," capable of mapping about 3 km² in one flight. The Matrice 4E is "Better" (40% improvement over M3E), and the Mavic 3E is "Good" and suited for smaller areas. Key Factors Driving Efficiency Differences Superior Sensor and Resolution: The P1's 45 MP full-frame sensor allows it to fly at a greater altitude than the M3E or M4E while maintaining the same Ground Sample Distance (GSD). Flying higher means each photo captures a significantly larger area, which reduces the required number of flight lines and overall mission time. Speed and Shutter Optimization: The Matrice 4E is designed for speed, boasting a faster maximum flight speed (21 m/s) and a quicker shooting interval (0.5s) compared to the M3E (15 m/s, 0.7s). This combination allows for faster ground coverage without motion blur. The P1 system is similarly optimized for speed with the M300/350 platform. Integrated Oblique Capture (M4E): The M4E enhances 3D modeling efficiency by up to 40% through its 5-directional smart oblique capture feature, minimizing the need for multiple, complex flight patterns. Payload Flexibility (M300/350 P1): The M300/350 platform combined with the P1 is a premier surveying solution, offering lens options (24mm, 35mm, 50mm) to fine-tune performance for different project scales and GSD requirements. Conclusion For maximizing acres mapped per hour under the specified parameters, the Matrice 300/350 P1 combination is the top performer. Its high-resolution, full-frame sensor and optimized flight planning capabilities are unmatched. The Matrice 4E is a highly capable and quicker-to-deploy alternative to the M3E but offers less power than the P1 system for large-scale projects. AirShot Live provides drone services that are professional quality; always using the best equipment to deliver top results. Our team of UAS part 107 certified pilots are insured and experienced using professional grade sensors for missions ranging from high resolution photography to action videos and live streaming events. Drone Equipment DJI, M300, M3, M3T, M4, Skydio, AgEagle, 4K, HD, 30-60 FPS, 21mp, 200X zoom, Thermal, Lidar, P1 Products and Services Drone Service, Aerial Inspections, Thermal Image, Radiometric, 3d Modeling, Aerial mapping, Topography Mapping, Rover GCP, 4k 1080p 720p Video, videography, Photography, Product Sales, Rental & Training, Certified RPIC Services Certificates: Certified FAA Drone UAS Pilots, Commercial Part107, FEMA ICS-100, Licensed, insured and bonded, DB: Property Damage Inspection, Thermal Inspection, Real Estate photography
