Probing class lecture - early preview

Lecture on oscilloscope probing, introducing many types of probe and discussing Theory of operation Tricks for maximizing performance Non-idealities and limitations Pros and cons vs other probe designs This is a practice/test session for a class I will be teaching in the future, to test pacing and gather early student feedback. The final class will be approximately half a day and include both lecture and lab components. 1:00 Introduction 12:20 Direct coaxial input 22:38 R-C divider probes 1:03:40 Resistive probes 1:31:40 High impedance active probes 1:44:20 Active differential probes 2:02:10 Power rail probes 2:13:30 Nearfield loop probes 2:19:05 Current probes 2:24:00 High voltage probes 2:29:17 Miscellaneous tips/tricks, conclusions
