Pickering's 21-Slot PXIe Chassis - 42-927

Our 21-slot PXIe, featuring 20 hybrid slots—the highest number available—supports various PXI and PXIe modules from any vendor. We designed this chassis to potentially eliminate the need for two chassis, saving costs, rack space, and reducing system complexity. Our innovative "Next Gen" enclosure design includes an easily removable rear fan tray and direct convection design, extending the ambient temperature range (0°C to +55°C) and providing high cooling capacity (100 W per slot up to 40°C). It also includes two, slot-in, modular power supplies for easy serviceability and scalability. These come with EMC class B 900W power supplies standard—upgradeable to 1800W with exceptional cooling capacity for high-power applications. Remote monitoring of power supply voltages, internal temperatures, and cooling fan speeds is accessible via a rear panel port. The Gen 2 PCIe backplane technology offers an attractive price/performance balance compared to ultra-high-performance Gen 3 chassis and competitors. Due to a high peripheral slot count, the chassis accommodates a single controller slot. We recommend our PCIe to PXIe remote control interface kit (43-921) or the highest-performance single-slot PXIe controller (43-920). For turnkey customers, we offer our integration service providing a fully functional chassis with an embedded controller, Windows OS, necessary drivers, and PXI/PXIe modules out of the box.
