Motorized Stages - 39 mm Diameter Motion Control Rotary Stages

Motorized Stages - Miniature High Resolution Rotary Stages Motorized Rotary Stages - Optimal Engineering Systems, Inc. (OES) has introduced high precision, low profile, miniature size rotary stages, the AR39-AH series. This series of high precision miniature size motorized rotary stages is just 35 mm (1.378 in.) high and the foot print including the standard 2-phase 1.8 degrees stepper motor is only 58 mm (2.283 in) by 100.5 mm (3.957 in.). The tables have a precision pattern of 6 8-M2x4L threaded mounting holes in the rotary table for fixtures or tooling, and an 8 mm (0.315 in) diameter through hole. The diameter of the AR39-AH Miniature Rotary Table is 39 mm (1.535 in.) and range of travel is a full 360 degrees of continuous rotation. The table is driven by a 120:1 worm gear at speeds up to 75 degrees per second and has a resolution of 0.001 degrees (3.6 arc-sec) with a 10 micro-step per step stepper motor driver, and parallelism of 50 microns. The knob mounted at the back of the motor for manual adjustment, can be replaced with a with quadrature incremental optical encoder for precision position verification. An optional servo motor with a quadrature incremental optical encoder is available for closed servo loop operation offering higher speeds and greater resolution. This low cost, low profile Motion Control AR39-AH Miniature Rotary Stage features a positional accuracy of 0.05 degrees (180 arc-sec) making it ideal for: Microscopy, laser positioning and machining, inspection, assembly, testing, and other critical applications. This black anodized stage has a load capacity of 3 kg (6.6 lbs.) and there is an indicator scale for visual sighting of the angle of rotation. This motorized rotary stage requires a Motion Controller that can be ordered as a complete plug-and-play system with RS-232, USB, joystick, trackball, and keypad control. For additional information contact our sales team at Optimal Engineering Systems, Inc. (OES), 6901 Woodley Ave, Van Nuys, CA 91406; Tel 888-777-1826, +1 818-222-9200, E-Mail sales@oesincorp.com or visit the website at http://www.oesincorp.com About OES – Optimal Engineering Systems, Inc. (OES) is a supplier of motorized and manual Motion Control Single and Multi-axis Stages, and Motion Controllers. High precision stages from OES includes: Linear Motion Stages, Rotary Motion Stages, Goniometer Stages, Vertical axis Stages (also called Z axis Stages, Elevator Stages, and Labjacks), and Gimbal Mounts (stages). Available as Stepper Motor Stages and Servo Motor Stages, the stages are available as a complete Plug-and-Play Motion Control System with a Single or Multi axis Controller, Joystick, Keypad, and Custom Length Cables. Capable of Submicron Positioning the Servo Motor Stages can be supplied with a Brushless DC or Brushed DC Servo Motor with Quadrature Optical Encoders for closed loop applications. Applications include: Animation, automated assembly systems, automation, CNC machines, flight simulation, inspection systems, linear and rotary stages, machine tools, medical devices, motion control camera boom systems, optical comparators, CMMs, pan-tilt gimbals, PCB assembly & inspection, pick-and-place, positioning stages, robotics, scanners, security cameras, telescope drive mechanisms, time-lapse photography and winders, identifying crystals, examining cutting edges of medical instruments, estimating hyperspectral bidirectional reflectance, gloss measurements, measurements of radiation patterns of LEDs, directing lasers, aligning mirrors, and manufacturing quartz oscillator plates using quartz cutting X-rays. #motorizedstage #motorizedrotarystage .
